PLX-9200 MULTI PRESS
NEWS
MULTI PRESS
Code: PLX-9200
PLX-9200 MULTI PRESS
  • KEY POINTS
  •  PRESS SYSTEM
    Single-lever
     FOAM CUSHIONS HIGH DENSITY
    with PU upholstery
     ADJUSTMENT
    Press arm starting position adjustable in 6 positions
    Gas spring-assisted pantograph seat height with 5 positions
    Backrest depth adjustable to 3 positions
     Weight Stack of 100 kg
    with integral protective shroud
Images and data presented in the catalog and on the website's product sheets may vary in some details from the original products
loading ... COMPARE COMPARE NOW

Technical Specifications

Product Code
Product CodePLX-9200
Cushioning
CushioningHigh-density foam with PU upholstery
Maximum User Weight
Maximum User Weight120 Kg
Application
ApplicationPROFESSIONAL
Features
Features
  • Weight Stack 100 kg steel
  • Pulley System made of POM, a material with excellent sliding characteristics and superior wear resistance - PREMIUM GRADE bearings. Steel cable system ø 5 mm, maximum load 1500 kg.
  • Adjustments for the pressing lever's starting position across 6 positions
  • Adjustments for seat height across 5 positions
  • Adjustments for backrest depth across 3 positions
Frame
FrameTubular steel with oval section 50x100 mm - 3 mm thickness, and round section ø 60 mm - 3 mm thickness
Product Weight
Product Weight235 kg
Product Dimensions
Product Dimensions1365x1363x1602 mm
Packaged Product Weight
Packaged Product Weight264 kg
Coating
CoatingDouble epoxy powder coating, scratch-resistant. Tubular frame treated with sandblasting and phosphating.
Certifications
CertificationsEN20957-1 / EN957-2 Class S
EAN
EAN8029975807003
